User-Friendly Structure
● Light weight and small footprint: only 5kg
● Open structure: easy to place different models
Even Faster Scan Speed
With increased scan speed, a single jaw scan can be finished in 12 seconds. The entire process of a separate-die order can be completed within 2 minutes and a non-separated-die order within 2.5 minutes.
Intelligent Add-Scan
When it comes to gaps, the AutoScan-DS-EX Pro can compute an optimized scan path and rescan to fill the unscanned holes automatically. Users don’t have to rescan manually.
Optimized Non-Separated Model Scan
Intelligent path planning for non-separated model scan ensures optimum scan results and higher efficiency.
Full range of Articulators
The AutoScan-DS-EX Pro supports scanning multiple types of articulators on the market.
Static & Dynamic Articulator Scan
Apart from the existing static scanning mode, a new dynamic scanning mode is now available to capture the full relationship of both jaws and further improve precision of occlusion. This added feature is easy to operate and will result in greater efficiency.
All-In-One Scan
This new all-in-one scan method allows scan of quadrant models and dies at the same time, which largely simplifies the scan process and improve the scan efficiency by almost 50%.
Versatile Application
AutoScan-DS-EX Pro supports multiple dental scan applications, including wax-up, abutment, die, plaster model, impression, articulator and texture.
Specifications
| Camera resolution | 1.3 MP |
| Scan time | 8 s for bite scan; 12 s for upper / lower jaw scan; 13 s for 1-4 dies scan; 21 s for 5-8 dies scan; 58 s for impression scan |
| Output format | STL / OBJ / PLY |
| Light source | Blue light |
| Dimensions | 260x270x420 mm |
| Weight | 5 kg |
| Interface | USB 3.0 |
| Power supply | DC24 V |
