Denture Base DT20

Shining 3D Denture Try-In DT20

Shining 3D Denture Try-In DT20 is a Class 2 resin designed for printing denture try-in restorations.

The material provides sufficient flexural strength and impact resistance while maintaining controlled viscosity for stable printing. Post-cured parts show good dimensional stability without excessive brittleness, making it suitable for clinical try-in use.

DT20 offers stable colour appearance with no noticeable taste and allows easy cleaning after printing. Multiple gingiva shades are available to support natural gingival appearance during try-in evaluation.

Physical Properties – Liquid

• Colour: Regular Pink

• Viscosity @25 °C: 750 cps

• Wavelength: 405 nm

Mechanical Properties – Post-Cured Parts

• Flexural Strength:

  • 98 MPa (ISO 178)

  • 75 MPa (ISO 20795-2)

• Flexural Modulus: 2800 MPa (ISO 178)

• Impact Strength: > 2.5 kJ/m² (ISO 180)

• Elongation at Break: > 7% (ISO 527-1)

• Biocompatibility: Complies with ISO 10993-1

Post-Processing

• Cleaning: Manual cleaning with 95% ethanol, 20 seconds

• Recommended Curing: Fabcure 2 – 10 minutes at 60 °C
